GW-HQ-1100Z Series Automatic Roll to Sheet Cutting Machine with Auto Stacker

GW-HQ-1100Z Series Automatic Roll to Sheet Cutting Machine with Auto Stacker

Scope of Application:

The machine is suitable for horizontal and longitudinal cutting big jumbo roll materials, such as paper, laminated paper, printed paper, adhesive sticker, non-woven fabric and plastic film, etc. The machine is widely apply to paper products processing industry, printing and packaging industry

Please leave us a message or send an email for a specific price.
E-mail: gawangmachine@gawangmachine.com
WhatsApp:+8613388518910
ContactGet a Quote

Scope of Application:

The machine is suitable for horizontal and longitudinal cutting big jumbo roll materials, such as paper, laminated paper, printed paper, adhesive sticker, non-woven fabric and plastic film, etc. The machine is widely apply to paper products processing industry, printing and packaging industry

Performances and Features:

1. The machine adopt PLC system to control the cutting length with auto counting and alarming stop function.

2. Auto stacker device that could collect cut sheets automatically with auto lifting as height of paper pile.

3.Separated Unwinder stand adopts auto loading system that liberate the workforce

4. Highly cutting precision with low noise that is widely apply to paper products processing industry, printing and packaging industry

Main Technical Parameters:

Model

GW-HQ-1100Z

GW-HQ-1400Z

GW-HQ-1600Z

Max. Web Width

1100mm

1400mm

1600mm

Max. Unwider  Roll Diameter

¢1400mm

¢1400mm

¢1400mm

Cutting Length

300-1200mm(Cutting Length can be customized from 1300-1600mm)

300-1200mm

300-1200mm

Cross Cutting Speed

30-200 times/min

30-200 times/min

30-200 times/min

Precision of cross cutting

±0.2mm

±0.2mm

±0.2mm

Cutting Thickness

70-500g/m2

70-500g/m2

70-500g/m2

Max. pile stack height

Max. 1200mm

Max. 1200mm

Max. 1200mm

Total Power

8kw

10kw

14kw

Machine Weight

4000kg

5000kg

6000kg

Overall Dimension

5500×1870×1850mm

5500×2270×1850mm

5500×2570×1850mm
