Automatic Stacking Paper Cross Cutting Machine

Automatic Stacking Paper Cross Cutting Machine

Suitable for:
This machine is suitable for many paper, film, paper and film lamination and other best large roll cutting machine.
Scope and characteristics
1. With the continuous development and competition of the paper product processing industry and the printing industry, the automatic stacking cross-cutting machine has become one of the indispensable equipments of the paper product processing industry and the printing and packaging industry.
2. Adopting imported electronic parts and components, applying intelligent control more flexibly, making the machine easy to operate, easy to maintain, and ensuring that the machine maintains cutting accuracy and machine stability under high-speed operation.
3. It is highly praised by users of paper products processing industry and printing and packaging industry in various countries.
4. At the same time can feed 2 rolls, 4 rolls, 6 rolls (additional option)

Please leave us a message or send an email for a specific price.
E-mail: gawangmachine@gawangmachine.com
WhatsApp:+8613388518910
ContactGet a Quote

Suitable for:

This machine is suitable for many paper, film, paper and film lamination and other best large roll cutting machine.

Scope and characteristics

1. With the continuous development and competition of the paper product processing industry and the printing industry, the automatic stacking cross-cutting machine has become one of the indispensable equipments of the paper product processing industry and the printing and packaging industry.

2. Adopting imported electronic parts and components, applying intelligent control more flexibly, making the machine easy to operate, easy to maintain, and ensuring that the machine maintains cutting accuracy and machine stability under high-speed operation.

3. It is highly praised by users of paper products processing industry and printing and packaging industry in various countries.

4. At the same time can feed 2 rolls, 4 rolls, 6 rolls (additional option)



Main Technical Parameters:

Model

GW-HQ-1100B

GW-HQ-1400B

GW-HQ-1700B

Max Cutting Width

1100m

1400mm

1700mm

Max.Diameter of Unwinding

?1400mm

?1400mm

?1400mm

Cutting Length

300-1500mm

300-1500mm

300-1500mm

Cutting Speed

10-150 cut per minutes

10-150 cut per minutes

10-150 cut per minutes

Cutting Precision

±0.2mm

±0.2mm

±0.2mm

Thickness of Paper

80-500g/m2

80-500g/m2

80-500g/m2

Stacking Height

Max.1000mm

Max.1000mm

Max.1000mm

Total Power

11.5KW

11.5KW

13.5KW

Machine Weight

3800KG

3800KG

4100KG

Overall Dimension(L*W*H)

5500*3000*1800mm

5500*3000*1800mm

5500*3300*1800mm


Illustrate in detail:

The unwinding shaft selects the inflatable shaft/shaftless automatic feeding structure according to the demand;


Automatic counting, automatic fixed length, alarm stop, automatic tension control;

The receiving platform automatically rises and falls, automatically inserts labels, and automatically stacks;

Automatic correction, high precision;
