This machine is suitable for slitting and rewinding of various roll materials such as BOPP, PET, CPP, CPE, PVC, aluminum foil, paper, etc. It can be trimmed, slitted, rewinded and cut according to different needs.
This machine is suitable for slitting and rewinding of various roll materials such as BOPP, PET, CPP, CPE, PVC, aluminum foil, paper, etc. It can be trimmed, slitted, rewinded and cut according to different needs.
1. The main body of the whole machine adopts cast iron and steel structure.
2. The main driving roller adopts seamless steel tube
3. The main driving roller adopts rubber roller, the guide roller adopts aluminum roller (after hard chrome plate and special chasing treatment to avoid material scratch) and rubber roller
4. Host and winding shaft drive: use synchronous belt. Simple operation and efficiency.
|
Type |
GW-FQ-V800 |
GW-FQ-V1100 |
GW-FQ-V1300 |
|
Max. Web Width |
800mm |
1100mm |
1300mm |
|
Max. Web Diameter |
600mm |
600mm |
600mm |
|
Width of Final Roll |
30-800mm |
30～1000mm |
30～1200mm |
|
Slitting Rewinding Speed |
5～180m/min |
5～180m/min |
5～180m/min |
|
Tolerance of EPC |
＜±0.5mm |
＜±0.5mm |
＜±0.5mm |
|
Total Power |
2.2Kw |
3.5Kw |
3.5Kw |
|
Weight of Machine |
1300kg |
1600 kg |
1900kg |
|
Overall Dimension(LxWxH) |
3000×1200×1530mm |
2500×1200×1530mm |
2700×1200×1530mm |
This machine is suitable for slitting and rewinding of various roll materials such as BOPP, PET, CPP, CPE, PVC, aluminum foil, paper, etc. It can be trimmed, slitted, rewinded and cut according to different needs.
This machine is specially designed for the cutting of BOPP, LDPE, PE, PP, PET, PVC and other plastic films. It is an ideal equipment for printing and packaging companies.
