1. The casting adopts advanced resin sand modeling with clear internal structure, which can effectively increase the friction life of moving parts.
2. The display adopts a color LCD touch screen computer.
3. The computer's operating interface adopts a humanized design, making it easy for operators to operate.
4. The hydraulic pressure is adjustable.
5. The frame adopts the internationally popular split structure, which effectively improves the cutting accuracy of the machine and facilitates the maintenance work of the user.
6. The working platform is also equipped with a blowing structure, which is convenient for pushing and feeding paper.
Two-way linear guide:High positioning accuracy of thepaper cutter and more stable transmission.
Infrared protection system:Provide infrared grating loop protection system.
Hydraulic solenoid valve:An automatic basic element used to control fluid, express action, small power, and lightweight.
Bearing:Imported bearings are selected for the key parts. High precision,low noise, stable paper pushing and smooth paper cutting.
|
MODEL |
GW-QZ-13000CD |
GW-QZ-13000CDW-7 |
GW-QZ-13000DW-7 |
GW-QZ-13000D-10 |
|
Cutting max-width='100%' width |
1300 CM |
1300 CM |
1300 CM |
1300 CM |
|
screen size |
7" |
7" |
7" |
10.4" |
|
Touch function |
－ |
－ |
－ |
－ |
|
Automated functional |
|
automatic |
automatic |
automatic |
|
Storage capacity (team) |
－ |
500 |
500 |
2000 |
|
each team of Program capacity |
－ |
999 |
999 |
999 |
|
Sending speed |
6-－12 m/min |
6-－12 m/min |
6-－12 m/min |
6-－18 m/min |
|
double guide and ball screw |
★ |
★ |
★ |
★ |
|
Chrome plated worktable |
★ |
★ |
★ |
★ |
|
Increase additional platforms |
optional |
optional |
optional |
optional |
|
Single hydraulic drive |
★ |
★ |
|
|
|
Double hydraulic drive |
|
|
★ |
★ |
|
HSS Knife |
optional |
optional |
optional |
optional |
|
Electromagnetic knife lock |
－ |
－ |
★ |
★ |
|
Self diagnosis system |
－ |
★ |
★ |
★ |
|
After the table Safety housings |
optional |
optional |
optional |
optional |
|
Foot stepped on pressure |
★ |
★ |
★ |
－ |
The machine is equipped with a ball screw and adopts imported machinery and equipment to make the machine more precise, without backlash and higher rigidity. PLC adopts international brands and has the advantages of high reliability and strong anti-interference ability, which greatly reduces the possibility of poor electrical contact and has complete channel protection and various forms of filter circuits. Air cushion workbench: The machine automatically unloads/takes paper, the work flow is faster, and labor is saved.
Paper Cutting Machine is specialized in cut the printing paper of various kinds,paper products,plastic,thin film,leather,slice of non-ferrous metal,etc.
1. The casting adopts advanced resin sand modeling with clear internal structure, which can effectively increase the friction life of moving parts. 2. The display adopts a color LCD touch screen computer. 3. The computer's operating interface adopts a humanized design, making it easy for operators to operate. 4. The hydraulic pressure is adjustable. 5. The frame adopts the internationally popular split structure, which effectively improves the cutting accuracy of the machine and facilitates the maintenance work of the user. 6. The working platform is also equipped with a blowing structure, which is convenient for pushing and feeding paper.
Paper Cutting Machine is specialized in cut the printing paper of various kinds,paper products,plastic,thin film,leather,slice of non-ferrous metal,etc.
Paper Cutting Machine is specialized in cut the printing paper of various kinds,paper products,plastic,thin film,leather,slice of non-ferrous metal,etc.
