Paper Cutting Machine is specialized in cut the printing paper of various kinds,paper products,plastic,thin film,leather,slice of non-ferrous metal,etc.
Can be cut PVC material:
It is designed according to customers' cutting different material needs, which solves the needs of cutting special materials such as PVC, cardboard, mud paper, and grayboard paper, and fills the gap in China.
Optional frequency conversion speed adjustment function:
The speed can be adjusted according to the customer's cutting different material requirements to improve work efficiency and quality.
Matte chrome-plated air cushion workbench:
The machine workbench adopts matt chrome-plated spray paint, with air cushion and blowing function, which is more convenient and labor-saving, and at the same time extends the service life of the machine.
Tie rod structure of paper press:
The left and right tie rods of the paper press adopt a connected suspension rod structure, which is more durable and has a longer service life.
Domestic servo motor:
The servo motor has excellent stability. Even if the machine has been replaced for many years, it will not oscillate, but it can achieve stable operation and long service life.
Product parameters
|
MODEL |
GW-QZ-1150D |
GW-QZ-1150DW-7 |
GW-QZ-1150DW-7 |
GW-QZ-1150DH-10 |
GW-QZ-1150DH-15 |
|
Cutting max-width='100%' width |
115 CM |
115 CM |
115 CM |
115 CM |
115 CM |
|
screen size |
7" |
7" |
7" |
10.4" |
15" |
|
Touch function |
－ |
－ |
－ |
★ |
★ |
|
Automated functional |
manual |
automatic |
automatic |
automatic |
automatic |
|
Storage capacity (team) |
－ |
500 |
500 |
5000 |
5000 |
|
each team of Program capacity |
－ |
999 |
999 |
999 |
999个 |
|
Sending speed |
6-－12 m/min |
6-－12 m/min |
6-－12 m/min |
6-－18 m/min |
6-－18 m/min |
|
double guide and ball screw |
★ |
★ |
★ |
★ |
★ |
|
Chrome plated worktable |
★ |
★ |
★ |
★ |
★ |
|
Increase additional platforms |
optional |
optional |
★ |
★ |
★ |
|
Double worm wheel drive |
|
|
★ |
★ |
★ |
|
Double hydraulic drive |
★ |
★ |
|
|
|
|
HSS Knife |
optional |
optional |
optional |
optional |
optional |
|
Electromagnetic knife lock |
★ |
★ |
★ |
★ |
★ |
|
Self diagnosis system |
－ |
★ |
★ |
★ |
★ |
|
After the table Safety housings |
optional |
optional |
optional |
optional |
optional |
|
Foot stepped on pressure |
★ |
★ |
★ |
★ |
★ |
Delivery packing
Paper Cutting Machine is specialized in cut the printing paper of various kinds,paper products,plastic,thin film,leather,slice of non-ferrous metal,etc.
Paper Cutting Machine is specialized in cut the printing paper of various kinds,paper products,plastic,thin film,leather,slice of non-ferrous metal,etc.
Paper Cutting Machine is specialized in cut the printing paper of various kinds,paper products,plastic,thin film,leather,slice of non-ferrous metal,etc.
The machine is equipped with a ball screw and adopts imported machinery and equipment to make the machine more precise, without backlash and higher rigidity. PLC adopts international brands and has the advantages of high reliability and strong anti-interference ability, which greatly reduces the possibility of poor electrical contact and has complete channel protection and various forms of filter circuits. Air cushion workbench: The machine automatically unloads/takes paper, the work flow is faster, and labor is saved.
1. The casting adopts advanced resin sand modeling with clear internal structure, which can effectively increase the friction life of moving parts. 2. The display adopts a color LCD touch screen computer. 3. The computer's operating interface adopts a humanized design, making it easy for operators to operate. 4. The hydraulic pressure is adjustable. 5. The frame adopts the internationally popular split structure, which effectively improves the cutting accuracy of the machine and facilitates the maintenance work of the user. 6. The working platform is also equipped with a blowing structure, which is convenient for pushing and feeding paper.
