The machine is suitable for slitting big jumbo roll materials, such as paper, double adhesive paper, straw paper, copper baord paper, white board, aluminum foil, PVC and plastic film, etc. The machine is widely apply to paper products processing industry, printing and packaging industry
Scope of Application:
The machine is suitable for slitting big jumbo roll materials, such as paper, double adhesive paper, straw paper, copper baord paper, white board, aluminum foil, PVC and plastic film, etc. The machine is widely apply to paper products processing industry, printing and packaging industry
Performances and Features:
1. The machine adopt PLC system to control the cutting length with auto counting and alarming stop function.
2. Slitting and rewinding part are controlled by servo motor, ensure machine running stable in high speed.
3. Rewinding adopts two air shafts and can be auto unloading.
4. Machine comes with slitting function (blade/circular knife) and equipped with trim reject fan to remove the slit edge of web
5. Unwinder adopts hydraulic auto loading system and equipped with web guiding system.
Main Technical Parameters:
|
Model |
SLD-1300 |
SLD-1600 |
SLD-2000 |
SLD-2300 |
SLD-2600 |
|
Max. Web Width |
1300mm |
1600mm |
2000mm |
2300mm |
2600mm |
|
Max. Unwinder Diameter |
￠1800mm |
￠1800mm |
￠1800mm |
￠1800mm |
￠1800mm |
|
Max. Rewinder Diameter |
￠1500mm |
￠1500mm |
￠1500mm |
￠1500mm |
￠1500mm |
|
Min. Rewind Web Width |
40mm |
40mm |
40mm |
40mm |
40mm |
|
Slitting Speed |
30-450m/min |
30-450 m/min |
30-450 m/min |
30-450 m/min |
30-450 m/min |
|
Precision of Slitting |
±0.2mm |
±0.2mm |
±0.2mm |
±0.2mm |
±0.2mm |
|
Cutting Thickness |
30-500g/m2 |
30-500g/m2 |
30-500g/m2 |
50-500g/m2 |
50-500g/m2 |
|
Total Power |
56kw |
56kw |
56kw |
56kw |
56kw-66kw |
|
Machine Weight |
13000kg |
14500kg |
16000kg |
18000kg |
20000kg |
|
Overall Dimension |
8500*3500*2700mm |
8500*3800*2700mm |
8500*4200*2700mm |
8500*4500*2700mm |
8500*4800*2700mm |
Certificates
The machine is suitable for slitting big jumbo roll materials, such as paper, double adhesive paper, straw paper, copper baord paper, white board, aluminum foil, PVC and plastic film, etc. The machine is widely apply to paper products processing industry, printing and packaging industry
This machine suitable for a lot of Film(PVC,bopp,opp,Pet,etc.),paper,paper&film laminated etc best jumbo rollcutting machine.It is high quality cuttingmachine in China.
This machine is used to produce thermal paper, bond paper, cash register paper, fax paper, POS paper, ATM paper and other small ribbon rolls and other materials. Make the equipment more stable, high speed and low noise, and the scope of application is wider.
