This machine suitable for a lot of Film(PVC,bopp,opp,Pet,etc.),paper,paper&film laminated etc best jumbo rollcutting machine.It is high quality cuttingmachine in China.
1. The machine adopts torque motor control, automatic taper tension, and center winding mode. The frequency conversion speed regulation is active only to maintain a balanced operation during acceleration.
2. Automatic meter counting and alarm function. The rewinding adopts an inflatable shaft structure, which is easy to unload and operate.
3. The unwinding adopts the photoelectric automatic correction and correction system, so that irregular materials can be cut normally.
4. Round knife slitting waste edge automatic removal device.
5. Pneumatic automatic feeding, equipped with inflatable shaft.
The main technical parameters:
|
Model |
GW-FQ-1100A |
GW-FQ-1400A |
GW-FQ-1600A |
|
Max.Width of Unwinding |
1100mm |
1400mm |
1600mm |
|
Max.Diameter of Unwinding |
Ø1400mm |
Ø1400mm |
Ø1400mm |
|
Min.Slitting Width |
30mm |
30mm |
30mm |
|
Max.Diameter of Rewinding |
Ø1000mm |
Ø1000mm |
Ø1000mm |
|
Machine Speed |
350m/min |
350 m/min |
350 m/min |
|
Slitting Speed |
300m/min |
300m/min |
300m/min |
|
Total Power |
23KW |
23KW |
23KW |
|
Machine Weight |
3500KG |
3800KG |
4500KG |
|
Overal Dimension(L*W*H) |
3500*3100*1900mm |
3500*3400*1900mm |
3500*3700*1900mm |
This machine suitable for a lot of Film(PVC,bopp,opp,Pet,etc.),paper,paper&film laminated etc best jumbo rollcutting machine.It is high quality cuttingmachine in China.
The machine is suitable for slitting big jumbo roll materials, such as paper, double adhesive paper, straw paper, copper baord paper, white board, aluminum foil, PVC and plastic film, etc. The machine is widely apply to paper products processing industry, printing and packaging industry
This machine is used to produce thermal paper, bond paper, cash register paper, fax paper, POS paper, ATM paper and other small ribbon rolls and other materials. Make the equipment more stable, high speed and low noise, and the scope of application is wider.
