Scope of Application:
The machine is special designed for slitting and cross cutting the big jumbo roll materials to A4/A3 size and other big jumbo roll materials, such adhesive sticker, etc. The machine is widely apply to paper products processing industry, printing and packaging industry
Scope of Application:
The machine is special designed for slitting and cross cutting the big jumbo roll materials to A4/A3 size and other big jumbo roll materials, such adhesive sticker, etc. The machine is widely apply to paper products processing industry, printing and packaging industry
Performances and Features:
1. The machine adopt PLC system to control the cutting length with auto counting and alarming stop function.
2. The machine can be equipped 1,2 or 4 unwinders and cross cutting at the same time.
3. Machine comes with slitting function (for A4/A3 paper size) and equipped with trim reject fan to remove the slit edge of web
4. Highly cutting precision with low noise that is widely apply to paper products processing industry, printing and packaging industry
Main Technical Parameters:
|
Model |
GW-HQ-A4-1100 |
GW-HQ-A4-1400 |
GW-HQ-A4-1600 |
|
Max. Web Width |
1100mm |
1400mm |
1600mm |
|
Max. Unwinder Diameter |
￠1400mm |
￠1400mm |
￠1400mm |
|
Cutting Length |
A4/A3 |
A4/A3 |
A4/A3 |
|
Cross Cutting Speed |
30-200 times/min |
30-200 times/min |
30-200 times/min |
|
Precision of cross cutting |
±0.2mm |
±0.2mm |
±0.2mm |
|
Cutting Thickness |
70-500g/m2 |
70-500g/m2 |
70-500g/m2 |
|
Max. pile stack height |
Max. 60mm |
Max. 60mm |
Max. 60mm |
|
Total Power |
16-20kw |
16-20kw |
18-22kw |
|
Machine Weight |
6000-8000kg |
8000-10000kg |
10000-13000kg |
|
Overall Dimension (Including Delivery Table) |
Sheeting Machine: (12000) 17000*3200*2200 packing machine:3200*4000 Roll to sheet cutting machine Packing Machine |
Sheeting machine:(12000)17000*3500*2200 Packing machine:3200*4000 |
Sheeting machine:(12000) 17000*3700*2200 Packing machine:3200*4000 |
Scope of Application: The machine is special designed for slitting and cross cutting the big jumbo roll materials to A4/A3 size and other big jumbo roll materials, such adhesive sticker, etc. The machine is widely apply to paper products processing industry, printing and packaging industry
High speed in copy paper spiral cutting and packaging production line is our company in many years roll paper cutting mechanism on the based of the experience ,absorption of advanced small cutting and 3 D packaging technology, the independent innovation, and have patented technology of a new models, mainly for senior A4 paper ‘s cutting and packing area.
Scope of Application: The machine is special designed for slitting and cross cutting the big jumbo roll materials to A4/A3 size and other big jumbo roll materials, such adhesive sticker, etc. The machine is widely apply to paper products processing industry, printing and packaging industry
High speed in copy paper spiral cutting and packaging production line is our company in many years roll paper cutting mechanism on the based of the experience ,absorption of advanced small cutting and 3 D packaging technology, the independent innovation, and have patented technology of a new models, mainly for senior A4 paper ‘s cutting and packing area.
High speed in copy paper spiral cutting and packaging production line is our company in many years roll paper cutting mechanism on the based of the experience ,absorption of advanced small cutting and 3 D packaging technology, the independent innovation, and have patented technology of a new models, mainly for senior A4 paper ‘s cutting and packing area.
