High speed in copy paper spiral cutting and packaging production line is our company in many years roll paper cutting mechanism on the based of the experience ,absorption of advanced small cutting and 3 D packaging technology, the independent innovation, and have patented technology of a new models, mainly for senior A4 paper ‘s cutting and packing area.
|
Model |
A4-20 |
|
Sheeting Unit |
|
|
Unwinding Paper Reels |
4 |
|
Number of Pocket |
4 |
|
Width of Paper Roll(mm) |
846-850; 646 |
|
Net Cutting Width(mm) |
840; 640 |
|
Width of Sheeted Paper (mm) |
210 |
|
Length of Sheeted Paper (mm) |
297 |
|
Diameter of Paper Roll(mm) |
400-1300 |
|
Diameter of Core Chuck(mm) |
3”(76.2mm) or 6”(152.4mm) |
|
Paper GSM(gsm) |
60-100 |
|
Paper Quantity per Ream (pcs) |
300--500 |
|
Max. Ream Height(mm) |
65 |
|
Working Speed of paper feeding(m/min) |
200--270m/min (Remark: the actual running speed is effected by paper quality etc.) |
|
Working Cutting Speed (times/min) |
750-780 |
|
Ream Discharging speed (reams/min) |
20—25 (based on 500 sheets per ream) |
|
Max. Knife Loading(gsm) |
600 (6×100) |
|
Paper cutting accuracy(mm) |
±0.2 |
|
Requirement for paper Reel |
1. Stable Speed 2. No splice in paper roll 3. Qualified paper. |
|
Transmission |
AC Frequency conversion, stepless speed regulating |
|
Main power source |
380v/50Hz 3phase 4 wires |
|
Control voltage |
220V AC/24V DC |
|
Power(Kw) |
20 |
|
Overall dimension(m) (LxWx H) |
18x2.96x2.1 |
|
Weight（T） |
19 |
|
Wrapping Unit |
|
|
Production Speed(reams/min) |
20-25 |
|
Motor power(Kw) |
6.5 |
|
Heating power(Kw) |
2.25 |
|
Compressed air(mpa) |
0.6—0.8 |
High speed in copy paper spiral cutting and packaging production line is our company in many years roll paper cutting mechanism on the based of the experience ,absorption of advanced small cutting and 3 D packaging technology, the independent innovation, and have patented technology of a new models, mainly for senior A4 paper ‘s cutting and packing area.
High speed in copy paper spiral cutting and packaging production line is our company in many years roll paper cutting mechanism on the based of the experience ,absorption of advanced small cutting and 3 D packaging technology, the independent innovation, and have patented technology of a new models, mainly for senior A4 paper ‘s cutting and packing area.
Scope of Application: The machine is special designed for slitting and cross cutting the big jumbo roll materials to A4/A3 size and other big jumbo roll materials, such adhesive sticker, etc. The machine is widely apply to paper products processing industry, printing and packaging industry
High speed in copy paper spiral cutting and packaging production line is our company in many years roll paper cutting mechanism on the based of the experience ,absorption of advanced small cutting and 3 D packaging technology, the independent innovation, and have patented technology of a new models, mainly for senior A4 paper ‘s cutting and packing area.
Scope of Application: The machine is special designed for slitting and cross cutting the big jumbo roll materials to A4/A3 size and other big jumbo roll materials, such adhesive sticker, etc. The machine is widely apply to paper products processing industry, printing and packaging industry
